CPU Core2 Duo E6400 2.5 GHz for Abilis Base-P or Core2 Duo E6550 CPU 2.5 GHz for Abilis Base-Q;

1024 MB RAM DDR2 for Abilis Base-P or 4096 MB RAM DDR2 for Abilis Base-Q.

The other components remain the same:

512MB Compact-Flash modules for boot;

PC platform with 2 PCI-slots and 2 PCI Express;

2 RS-232 ports;

Hardware Watchdog processor;

10 USB ports;

1 Gigabit Ethernet;

3 Power out connector useful to supply UMTS BOX2 or POTSBOX.

up to 8 ISDN-2 or ISDN30 ports. Refer to the following chapters: Section 2.10.1, “QPRIX”, Section 2.10.3, “PB44X”, Section 2.10.6, “BRI-HFC4 / BRI-HFC8”, Section 2.10.2, “PB22”.

up to 32 analogue extensions (for “internal” telephones or fax). Refer to the following chapter: Section 2.10.7, “POTS 4/8/16”.

up to 256 analogue extensions (for “internal” telephones or fax). Refer to the following chapter: Section 2.10.10, “POTSHUB”.

up to 2 Ethernet ports. Refer to the following chapter: Section 2.10.11, “Ethernet”.

up to 16 Ethernet ports. Refer to the following chapter: Section 2.10.13, “QUAD-Ethernet”.

up to 2 Gigabit Ethernet ports. Refer to the following chapter: Section 2.10.12, “GigaEthernet”.

up to 10 xDSL concurrent connections to the Internet. Refer to the following chapter: Section 2.11.1, “ADSL modem”.

up to 10 UMTS gateways (up to 16 simultaneous calls between the fixed and the mobile network). Refer to the following chapter: Section 2.11.4, “UMTS-BOX2”.

up to two 5” 5200 RPM SATA Hard-Drives.
